MYSTERE II/IV: 3
MAIN FEATURES
Inward retracting,
single wheel, main
gear unit
Landing/taxi light on nosegear oleo
Forward retracting, single
wheel, nose gear unit
Airbrake
(extended)
Airbrakes
(extended)
Mystère IIC (armed and dirty)
Whip antenna
625 lt, (138 Imp gal, 165 US gal)
fuel tank on inboard wing pylon
Derveaux 148 gun laying radar
Provision for 200 lt (44 Imp gal,
53 US gal) aerodynamic tip tanks
Gun camera
2 x 30 mm (1.18 in) DEFA 552 cannons
with 100 rounds per gun
Sadir Carpentier Mk.IV gunsight
Mystère IIC (armed)
Air data probe
Tailplane set low on tail fin
SNCASO E.86 ejector seat
Hispano-Suiza Nene 102B centrifugal turbojet
Airbrake, lower rear fuselage
Tailplanes with 32º
leading edge sweep
and elevators
Rearward sliding bubble canopy
Low-mounted wings with 32º leading
edge sweep and slight anhedral
Ranging radar bullet fairing
Split trailing
edge flap
Aileron set inboard
of wing tip
Tailfin with 50º
leading edge sweep
Whip antenna
Circular intake
with splitter plate
Three-piece windshield
Provision for
wingtip tanks
Fuselage based on Dassault Ouragan
lengthened by 35 cm (1 ft 1.75 in)
Pitot
Whip antenna, offset to port
NACA-style inlets
NACA-style inlets
Small light
Mystère IIC (clean)
ILLUSTRATIONS: © ADRIAN DAVID MOORE 2015 • NO ITEMS MAY BE REPRODUCED WITHOUT THE PERMISSION OF THE COPYRIGHT HOLDER
