MAIN FEATURES
Airbrakes shown open)
Forward retracting, Steerable, single wheel nose gear unit with mudguard
Outward retracting, single
wheel, main gear unit
Retractable twin
wheel tail unit
J35F2 (armed and dirty)
Ericsson PS-11/A radar and
S7B collision course gunsight/
fire control system
Ericsson (Hughes)
S71N IR sensor
slaved to radar
antenna
30 mm (1.18 in) Aden revolver
cannon in starboard wing
Rb27 semi-active radar homing AAM on underfuselage pylon
Rb28 IR AAM on underwing pylon
VHF antenna
S.7 collision-course gunsight
J35F2 (armed)
1 x Svenska Flygmotor RM6C turbojet
with Model 67 afterburner
RS-35 zero-zero ejector seat
Conical radome
Cooling
intakes
(port and
starboard)
Retractable
tail wheel fairing
Fin tip pitot
Long, flattened
oval, fixed intakes
blended into wing
IR sensor fairing
Cannon in starboard
wing only
Rear-hinged bubble canopy
Intakes on spine
Air brakes
Mid-mounted double delta wing with
80º leading edge sweep on inboard
section and 57º on outboard
Servo
operated
trailing
edge
elevons
Fin bullet fairing
Three-piece
windshield
Large raked fin/rudder
Brake
chute
housing
Fixed auxiliary dorsal fin
J35F2 (clean)
J-35 DRAKEN: 3
SAAB J35 DRAKEN
